How to angle teeth of a gear

david_sun451
david_sun451 Member Posts: 2 ✭

Im trying to make dog teeth like annotated below, any ideas on how to make this in onshape? ive tried fillet, chamfer and played around with draft but to no avail.

Screenshot 2026-07-08 at 1.52.50 PM.png
Tagged:

Answers

  • andrew_downing102
    andrew_downing102 Member Posts: 12 ✭

    Something like this: https://cad.onshape.com/documents/de84ba5bf393d7d09ca79002/w/b4b8d32259f60b7006b54d3a/e/a9ccd33aea444c959bb479a6

  • Werner
    Werner Member Posts: 5 ✭✭

    The best way is with "Spur gear", you can find this in the
    Onchape Add features list
    it has all the possibilities

  • Werner
    Werner Member Posts: 5 ✭✭
