# blind hole at angle

Member Posts: 8 PRO
Hi
I'm trying to insert a blind hole at an angle. I read up and it was suggested drawing a 3D spline along the path the hole will follow and then setting a point normal plane off of the vertex to work from .
I have done this but cant seem to locate the hole at  the end of the spline and face of the plane.
Any ideas would be appreciated or is there an easier way to do this. Thanks
regards Stuart

• Member, Moderator, Onshape Employees, Developers Posts: 1,306
Philip Thomas - Onshape
• Member, Moderator, Onshape Employees Posts: 211
In order to use the Hole feature to create a hole through the part you will need a point and a plane perpendicular to the hole axis. You got the plane component but you will have to create a sketch on the plane and add a "point" where the spline connects with the plane. Please see my version here:

Tim Rice | User Experience | Support
Onshape, Inc.
• Moderator, Onshape Employees, Developers Posts: 1,338
Hi @stuart_hatherway

Looks like you're almost there! Only sketch points can be used to make holes, so in sketch 6 you'll have to "use" the endpoint of the 3d spline:

Then once you have the point in the sketch, you can use it as a selection for your hole.

Once I did this, I was able to make the hole, but the geometry was weird because the starting plane of the hole cut through the model:

My solution for this was to make the plane exist entirely outside the model by using a line-angle plane off of the top edge of the part (using the 3d fit spline as a reference for the 'angle' parameter):

And then when the hole is built, it looks correct!

Jake Rosenfeld - Modeling Team
• Moderator, Onshape Employees, Developers Posts: 1,338
Seems we all jumped on this one at the same time
Jake Rosenfeld - Modeling Team
• Member, Developers Posts: 2,327 PRO
edited September 2018
Seems we all jumped on this one at the same time
Cool.   Onshape staff rock.
Now please will one of you go and build me a single stick font
Owen S.
Production Engineer
HWM-Water Ltd
• Member Posts: 911 ✭✭✭✭✭
Now please will one of you go and build me a single stick font
yes, stick fonts are important here in machinery)
• Member, Developers Posts: 2,327 PRO
Flintstone font, love it

Yabba-dabba-do. O.S.
Production Engineer
HWM-Water Ltd
• Member Posts: 911 ✭✭✭✭✭
edited September 2018
Flintstone font, love it
then how do you love stickstone font

• Member, Developers Posts: 2,327 PRO
They had good CNC machines in those days....
Production Engineer
HWM-Water Ltd
• Member Posts: 8 PRO
Thank you everyone all sorted
